Model

SK-120W-12V-24V

Input Voltage

DC10V-16V

Output Voltage

DC24V±3%

Max Output Current

5A

Rated Power

120W

Max Power

150W

Transfer Efficiency

>90%

Quiescent Current

<100mA

Working Temperature

-20~+55℃

Size

120 x 64 x 40mm

Weight

0.35Kg

Packing

Neutral packing

Warranty

2 Years

Certification

CE and RoHS

Features

1.High-end integrated switching regulator module manufacturing.

2.Over-voltage,under-voltage,over temperature,short circuit protection.

3.Auto cool,IP40.

4.Aluminum alloy shell,heat eliminable.

Application

Can be widely used for car,bus,truck,interphone,FM audio system,surveillance system,etc.
