Model

SKA-40A-48V-24V

Input Voltage

DC40V-60V

Output Voltage

DC24V

Output Current

40A

Output Power

960W

Ripple

<200mVp

Static Current

<60mA

Transfer Efficiency

≥95%

Working Temperature

-30~80℃

IP Rating

IP68

Size

150 x 127 x 63mm

Weight

1.8Kg

Packing

Neutral packing

Warranty

2 Years

Certification

CE & RoHS

Features

1.High-end integrated switching regulator module manufacturing.

2.Over voltage, over current, over temperature, short circuit protection.

3.Aluminum alloy shell, heat eliminable.

Application

Can be widely used for car, interphone, LED light, FM audio system, surveillance system, etc.
