Model

SKA-3A-48V-24V

Input Voltage

DC30V-60V

Output Voltage

DC24V

Output Current

3A

Output Power

72W

Ripple

<40mVp

Static Current

<20mA

Transfer Efficiency

≥95%

Working Temperature

-40~85℃

IP Rating

IP67

Size

74 x 74 x 32mm

Weight

0.3Kg

Packing

Neutral packing

Warranty

2 Years

Certification

CE & RoHS

Features

1.High-end integrated switching regulator module manufacturing.

2.Over voltage, over current, over temperature, short circuit protection.

3.Aluminum alloy shell, heat eliminable.

Application

Can be widely used for car, interphone, LED light, FM audio system, surveillance system, etc.
